Page #145 background imageLoading...
Page #145 background image
Maintenance work on the carrier
7.10 Vehicle brake
16.08.2018
Maintenance manual 3 302 577 en 7 - 73
GMK7450
7.10 Vehicle brake
7.10.1 Checking brake lining thickness
Spare parts and
tools
– Measuring tool for brake linings.
s
M 3
Designation Quantity
per axle
line
GROVE part no.
1st and 2nd axle line (duplex brake)
Brake shoe with brake lining 4 03322112
Spring 4 03322110
Brake drum 2 01925703
3rd, 4th, 5th, 6th and 7th axle line (simplex brake)
Brake shoe with brake lining 4 03322121
Spring 4 02315393
Brake drum 2 01925703
