Maintenance work on the superstructure
8.10 Hydraulic system
16.08.2018
Maintenance manual 3 302 577 en 8 - 75
GMK7450
8.10.6 Changing the ventilation filter
Spare parts and
tools
Prerequisites – The engine must not be running and must be secured against unauthor-
ised use;
à P. 2 - 3.
• Remove the cap (2).
• Change the filter (3) and screw on the cap
tightly.
• Reset the display by pressing the pin (1)
down.
Designation Quantity GROVE part no.
Filter 1 03319602
O
Risk of damage to the environment from filter residues!
Store used hydraulic oil filter inserts in suitable receptacles and have them
disposed of prop
erly by qualified personnel.
