Manitowoc GROVE GMK7450 - Lubricant Applications List

Lubricants and consumables
6.1 Lubricants
16.08.2018
Maintenance manual 3 302 577 en 6 - 3
GMK7450
6.1.2 Lubricant applications list
Consec.
no.
Lubricant
type
Usage Fill quan-
tity
in litres
(gal
)
Mainte-
nance
interval
1 Engine oil
Diesel engine for carrier;
à P. 7 - 17 53 (14.0) M 6
Diesel engine for superstructure;
à P. 8 - 19 17 (4.5) M 6
2 Gear oil Transmission;
à P. 7 - 47 51 (13.5) Y 2
3 Gear oil
with 14 x 6 drive:
Transfe
r case;
à P. 7 - 52
12.8 (3.4) M 6
with 14 x 8 drive:
Transfer cas
e;
à P. 7 - 52
11.8 (3.1) M 6
1st axle line axle centre drive;
à P. 7 - 57 13.0 (3.5) M 12
5th axle line axle centre drive;
à P. 7 - 57 13.0 (3.5) M 12
4th axle line axle centre drive;
à P. 7 - 57 16.5 (4.4) M 12
only for 14 x 8 x 14 drive:
2nd axle line axle centre drive;
à P. 7 - 57
16.5 (4.4) M 12
6 or 8 x final drives;
à P. 7 - 60 2.7 (0.7) M 12
4 Gear oil
6 x suspension
struts;
à P. 7 - 77 1.5 (0.4) M 1
8 x suspension struts;
à P. 7 - 77 3.2 (0.84) M 1
5 Gear oil
2 x hoists;
à P. 8 - 46 11.5 (3.0) M 12
3 x slewing gears;
à P. 8 - 52 0.9 (0.24) M 12
6 Gear oil Pump transfer case;
à P. 8 - 66 3.8 (1.0) M 12
7 Hydraulic oil
Carrier hydraulic tank;
à P. 7 - 97 200 (53) M 12
Superstructure hydraulic tank;
à P. 8 - 82
1,780
(470)
M 12
s
