Manitowoc GROVE GMK7450 User Manual

Maintenance work on the carrier
7.8 Axle lines
16.08.2018
Maintenance manual 3 302 577 en 7 - 57
GMK7450
7.8.3 Axle centre drives – changing the oil
Oil, spare parts,
tools
1)
Additional equipment (2nd axle line driven)
– Receptacle, approx. 20 l (5.0 gal);
à P. 2 - 4.
Prerequisites – The truck crane must be raised on outriggers or parked over an inspection
pit.
– The
engine must not be running and must be secured against unauthor-
ised use;
à P. 2 - 3.
s
M 12
Gear oil
in litres (gal)
Designation
to DIN 51502
Specifications
Classification
GROVE part no.
Axle line 1+5:
13.0 (3.5) each
Axle line 2+4
1)
:
16.5 (4.4)
C - LPF MIL-L 2105 B
API-GL-5
Visco
sity:
Hyp SAE 90
ISO - VG 220
00552891
For drive Designation Quan-
tity
GROVE part no.
14 x 6 x 14
Gasket 30 x
36 Cu DIN 7603 3 00117151
Gasket 24 x 29 Cu DIN 7603 2 00117145
Gasket 36 x 42 Cu DIN 7603 3 01371208
14 x 8 x 14
Gasket 30 x
36 Cu DIN 7603 4 00117151
Gasket 24 x 29 Cu DIN 7603 4 00117145
Gasket 36 x 42 Cu DIN 7603 4 01371208
O
Risk of environmental damage due to leaking consumables!
Always let consumables drain into suitable recept
acles. Wipe up any con-
sumables that escape.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
