Maintenance work on the superstructure
8.6 Hoists
16.08.2018
Maintenance manual 3 302 577 en 8 - 43
GMK7450
8.6 Hoists
8.6.1 Checking the oil level
Spare parts and
tools
Prerequisites – The truck crane must be level and in on-road mode;
à Operating manual.
– The auxiliary hoist (additional equipment) is rigged;
à Operating manual.
– The engine must not be running and must be secured against unauthor-
ised use;
à P. 2 - 3.
Checking the oil
level
• Check that the oil level is visible between the
Min. and Max. marks (1).
If the oil level is too low
• Top up the oil; à P. 8 - 46.
W
Designation Quantity GROVE part no.
Gasket 14 x 18 Cu DIN 7603 2 00117131
Gasket 18 x 22 Cu DIN 7603 4 00117137
