Maintenance work on the superstructure
8.8 Slewing bearing
16.08.2018
Maintenance manual 3 302 577 en 8 - 59
GMK7450
8.8.2 Lubricating the gear teeth
Grease
H
Observe the instructions and safety instructions on the adhesive lubricating
grease packaging!
Prerequisites – The truck crane must be level and on outriggers;
à Operating manual.
– The main boom must be fully raised;
à Operating manual.
– The engine must not be running and must be secured against unauthor-
ised use;
à P. 2 - 3.
Greasing
A distinction is made between initial lubrication and subsequent lubrica-
tions:
s
Designation Quantity GROVE part no.
Adhesive lubricating grease (spray
can)
1 00
554205
G
Risk of crushing from the gear teeth!
Fingers may be crushed or clothing can be drawn into the open, rotating
pinion. For this reason, be
sure to remount the plate after lubricating.
