Manitowoc GROVE GMK7450 User Manual

Maintenance work on the carrier
7.3 Engine
16.08.2018
Maintenance manual 3 302 577 en 7 - 13
GMK7450
7.3.2 Topping up the oil
Data on the prescribed oil specifications; à Engine manufacturer’s documen-
tation
.
Oil
Prerequisites – The truck crane must be level.
– The engine must not be running and must be secured against unauthor-
ised use;
à P. 2 - 3.
Topping up the oil
• Add oil through the filler neck (2) up to the
Max. mark.
• Close the filler neck with the cap.
• Insert the dipstick (1) into the dipstick tube
after checking the oil level.
Engine oil
in litres
(gal)
Designation
to DIN 51502
Specifications
Classification
GROVE part no.
53 (14
.0) HD - CD CES 20081
Cummins
SAE 15 W-40
04162428
S
Risk of damage to the engine if the oil level is too high!
Do not overfill with oil; the oil level must not be higher than the max. mark
(arrow marking). Drain off oil if necessary;
à Engine manufacturer’s docu-
mentation
.
G
Risk of burns when the engine is hot!
During operation, the engine and add-on parts reach temperatures up to
400 °C (750 °F). Wear appropriate protective gloves and be careful not to
touch hot parts.
