Maintenance work on the carrier

7.9 Wheels

16.08.2018

Maintenance manual 3 302 577 en 7 - 67

GMK7450

7.9.3 Checking that the wheel nuts are tight

Spare parts and

tools

– Torque wrench for

650 Nm

(480 lbf ft).

Prerequisites – The engine must not be running and must be secured against unauthor-

ised use;

à P. 2 - 3.

Check the wheel

nuts

• Check the wheel nuts and the pressure

plates for damage.

• Replace any damaged wheel nuts or pres-

sure plates.

• Check the wheel nuts in the sequence (1-12)

for a tight fit – torque

650 Nm

(480 lbf ft).

M 1

Designation Quantity

per wheel

GROVE part no.

Wheel nut with pressure plate

for steel rims

12 01207756

Wheel nut with pressure plate

for aluminium rims

12 7659100000
