Spare parts required for maintenance
11.3 Spare parts for the carrier
16.08.2018
Maintenance manual 3 302 577 en 11 - 5
GMK7450
11.3 Spare parts for the carrier
Assemblies and spare parts
Carrier
GROVE-
Part number
Quantity, in single parts
For maintenance interval
W M 1 M 3 M 6 M 12
Engine
Air filter – mai
n filter 90025830
1 item when the symbol lights up
Air filter – back-up filter 90025831
Oil filter 04241344 1
Drain plug seal 04241329 1
Coolant cartridge 04241506 1
Fuel system
Filter 1 04256757 1
Filter 2 0
4241343 1
Exhaust system with ex
haust emission control
AdBlue/DEF filter 0424
1341 1
Transfer case
Gasket 30 x 36 Cu DIN 7
603 00117151 1 1
Gasket 16 x 20 Cu DIN 7603 00117134 1
Axle lines Axle centre drive (for max. 14 x 8 x 14)
Gasket 30 x 36 Cu DIN 7
603 00117151 4 4
Gasket 24 x 29 Cu DIN 7603 00117145 2 4
Gasket 36 x 42 Cu DIN 7603 01371208 4
Axle lines Final drive (for max. 14 x 8 x 14)
Gasket 24 x 29 Cu DIN 7
603 00117145 8 8
Wheels
Wheel nuts for steel rims 0120
7756
In case of damage;
12 each per wheel
Wheel nuts for aluminium rims 7659100000
s
