Page #348 background imageLoading...
Page #348 background image
Spare parts required for maintenance
11.2 Lighting
11 - 4 3 302 577 en Maintenance manual
GMK7450
16.08.2018
SUPERSTRUCTURE LIGHTING:
Marker lights, yellow:
(on the main boom head)
– Marker light; complete 03329569 LED
Red rear marker lights:
(on the turntable)
– Marker light 03329492 FPL 98 CKS
Yellow rotating beacon:
(on the turntable)
– Rotating beacon; complete 04156048
Inside light:
(in the crane cab)
– Cab light 01207144 R10 W 24 V 10
– Reading light 00439055 P25-1 24 V 21
Spotlight, attachable:
(at the front of the crane cab)
– Filament lamp 03326694 8GS007949101 35
Spotlight, electrically adjustable:
(at the front of the main boom)
– Gas discharge lamp 03142726 8GS009028001 35
Installation point GROVE part
n
umber
Designation Powe
r (W)
