Spare parts required for maintenance
11.2 Lighting
16.08.2018
Maintenance manual 3 302 577 en 11 - 3
GMK7450
White front marker lights:
(at the top on the driver's cab)
– Marker light 00438514 C5 W 24 V 5
Yellow additional lights for USA:
(at the top on the driver's cab)
– Yellow side marker light 03320937 LED
Outrigger beam spotlights:
(above the front and rear outrigger beams)
– Filament lamp 02316460 8GH 002090251 70
Yellow rotating beacons:
(on the driver's cab)
– Rotating beacon; complete 04156048
Inside lights:
(in the driver's cab)
– Filament lamp 00550434 K 24 V 10
Dashboard light:
(in the driver's cab; socket 12V)
– Filament lamp 04159964 Xenon 12V / 6W
s
Installation point GROVE part
number
Designation Power (W)
