Maintenance work on the carrier
7.8 Axle lines
16.08.2018
Maintenance manual 3 302 577 en 7 - 63
GMK7450
7.8.7 Lubricating longitudinal drive shafts
H
Check all drive shafts to see if they have grease nipples.
drive shafts with grease nipples must be serviced, drive shafts without
grease nipples are maintenance-free.
Grease, spare
parts, tools
–
Grease gun from the tool set.
Prerequisites – The truck crane must be raised on outriggers or parked over an inspection
pit.
– The
engine must not be running and must be secured against unauthor-
ised use;
à P. 2 - 3.
Greasing
Drive shafts (2) a
re
fitted only to the 14 x 8 x 14
drive.
• Check which drive shafts (1) and (2) have
lubricating nipples (3).
• Clean the grease nipples (3).
• Inject grease into the grease nipples until
grease escapes from the bearing points. Do
not inject grease with excessive force, other-
wise the lip seals may be damaged.
• Remove any grease that has escaped.
M 6
Lubricating
grease
Designation
to DIN 51502
Specifications
Classification
GROVE part no.
Grease KP - 1K - 50 DIN 51825 03233369
