Maintenance work on the carrier
7.7 Transfer case
16.08.2018
Maintenance manual 3 302 577 en 7 - 51
GMK7450
7.7 Transfer case
• Also adhere to the à Run-in regulations, P. 4 - 1.
7.7.1 General inspection
• Investigate any unusual noises made by the transfer case.
• Check the transfer case and the connections for leaks. If consumables are
leaking;
à Check the oil level, P. 7 - 51.
• Check that pipes and hoses are tightly connected and undamaged.
If any damage is found, report it to
Manitowoc Crane Care or an authorised
GROVE dealer or an authorised specialist workshop.
7.7.2 Check the oil level
Spare parts and
tools
– Clean receptacle, approx. 5 l (1.3 gal);
à P. 2 - 4.
Prerequisites – The truck crane must be raised on outriggers or parked over an inspection
pit.
– The
engine must not be running and must be secured against unauthor-
ised use;
à P. 2 - 3.
s
W
M 1
Designation Quantity GROVE part no.
Gasket 30 x 36 Cu DIN 7603 1 00117151
