Maintenance work on the carrier
7.6 Transmission
7 - 48 3 302 577 en Maintenance manual
GMK7450
16.08.2018
Changing
Draining oil
• Pull out the dipstick (1).
• Place a receptacle under the screw (2).
• Remove the screw and let the oil drain out.
Changing the oil filter
• Release the cap (1) and pull out the filters.
• Insert new filters.
• Replace the gaskets and tighten the caps –
torque 50-60 Nm (37-44 lbf ft).
• Replace the gasket and tighten the
screw (2) – torque 25-32 Nm (18-24 lbf ft).
G
Risk of scalding from gear oil at operating temperature!
You could scald yourself by gear oil escaping in an uncontrolled manner at
operating temperature. Wear
appropriate protective gloves and take care
not to come into contact with the gear oil.
O
Risk of environmental damage due to leaking consumables!
Always let consumables drain into suitable receptacles. Wipe up any con-
sumables that escape.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
