Maintenance work on the carrier
7.14 Hydraulic system
16.08.2018
Maintenance manual 3 302 577 en 7 - 93
GMK7450
Protecting the
hose from dirt
When storing the hose
• Close the hose ends (1) with the caps (2).
Connecting the
hose
• Only use a hose with a connecting piece.
• Remove the caps (4).
• Put the hose end into the receptacle (3).
• Remove the cap from the gauge port (1) and screw the connecting piece (2)
on to the gauge port – the gauge port opens.
s
S
Danger of contamination of the oil sample!
If the hose with the connecting piece is dirty, the dirt can contaminate the
oil sample in the sample container durin
g the sampling process. The labo-
ratory analysis would then be incorrect.
For flushing, always allow 2 litres (0.5 gal) of oil to flow through the hose
into a receptacle before filling the sample con
tainer.
O
Danger due to escaping hydraulic oil!
When you screw the connecting piece on to the gauge port, the gauge port
opens and oil flows out of the hose
. Put the hose end into a receptacle
before screwing on the connecting piece.
Always let consumables drain into suitable recept
acles. Wipe up any con-
sumables that escape.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
