Maintenance work on the superstructure
8.3 Engine
8 - 20 3 302 577 en Maintenance manual
GMK7450
16.08.2018
Changing
Oil filter
• Place a receptacle underneath the engine.
• Loosen the oil filter (1) using a strap wrench.
• Leave the receptacle in place for the oil
change.
Draining oil
The drain plug (1) is accessible from below, at
the side of the shallow oil pan.
• Unscrew the drain screw (1) and drain the oil
into the container.
• Fit a new gasket and tighten the drain
screw (1).
• Remove the receptacle.
Topping up the oil
• Top up with fresh oil through the filler
neck (2);
à P. 8 - 15.
O
Risk of environmental damage due to leaking consumables!
Always let consumables drain into suitable receptacles. Wipe up any con-
sumables that escape.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
O
Risk of environmental damage due to leaking consumables!
Use the supplied connecting piece and hose and a receptacle with sufficient
capacity to drain the oil.
