Electrical System
244
(
***
) Tractors with AutoSpeed only
Fuse No Circuit Amps
14 CAB SUSPENSION 7.5
15 OPEN -------
16 IMPLEMENT INTERFACE CONNECTOR UNSWITCHED B+ 10
17 FRONT CAB ROOF WORK LIGHTS 25
18 TURN SIGNAL LIGHTS 15
19 WARNING LIGHTS 5
20 TURN SIGNAL LIGHTS 15
21 NOT USED 20
22 OPEN -------
23 TAIL LIGHTS 5
24 BRAKE LIGHTS 20
25 INSTRUMENT CLUSTER SWITCHED B+ 7.5
26 MFD, DIFF LOCK 30
27 SEAT 15
28 FRONT SUSPENDED AXLE CONTROLLER SWITCHED B+, FRONT PTO 15
29 TRAILER CONNECTOR AUXILIARY POWER 30
30 INTERIOR LIGHT, RADIO CLOCK POWER, INSTRUMENT CLUSTER CLOCK POWER,
FRONT SUSPENDED AXLE CONTROLLER UNSWITCHED B+)
7.5
31 REAR WINDSCREEN WIPER/WASHER 15
32 FRONT WINDSCREEN WIPER/WASHER, ELECTRIC MIRRORS (CIRCUIT BREAKER) 15
33 HITCH CONTROLLER UNSWITCHED B+, (
***
) CLUTCH PEDAL SWITCHES 7.5
34 POWERSHIFT, 4TH AUXILIARY/REMOTE VALVE 20
35 REAR PTO, AUDIBLE ALARM, AUTOSPEED SWITCHED B+ 20
36 OPEN -------
37 GRID HEATER CONTROL MODULE SWITCHED B+, FUEL HEATER, FUEL SHUT-OFF,
FUEL AUTO ADVANCE, WATER IN FUEL
20
38 OPEN -------
39 CIGAR LIGHTER 10
40 ACCESSORY, INSTRUMENT CLUSTER, RADIO 7.5
41 REAR AUXILIARY POWER CONNECTOR, UNSWITCHED B+ 30
42 FRONT AUXILIARY POWER CONNECTOR, UNSWITCHED B+ 30
43 REAR AUXILIARY POWER CONNECTOR SWITCHED B+ 30
44 FRONT AUXILIARY POWER CONNECTOR SWITCHED B+ 30
