MI 2893 / MI 2892 / MI 2885 Memory List
108
3.22.1 General Record
This type of record is made by GENERAL RECORDER. Record front page is similar to the GENERAL
RECORDER setup screen, as shown on figure below.
Figure 81: Front page of General record in MEMORY LIST menu
Table 88: Recorder settings description
Record No.
Selected record number, for which details are shown.
FILE NAME
Record name on SD Card
Type
Indicate type of record: General record.
Interval
General record recording interval (integration period)
Start
General record start time.
End
General record stop time.
Size
Record size in kilobytes (kB) or megabytes (MB).
Table 89: Keys in General record front page screen
VIEW
Switches to the CHANNELS SETUP menu screen.
Particular signal groups can be observed by pressing on F1 key
(VIEW).
Keys in CHANNELS SETUP menu screen:
Selects particular signal group.
F1
