MI 2893 / MI 2892 / MI 2885 Events table
94
Shows poly-phase voltage interrupts only, according to the IEC 61000-4-
30 requirements. START time and Duration in table is referenced to
voltage interrupt only.
Shows selected waveform and inrush view.
Enters detail event view.
Returns to Events table group view screen.
Returns to “RECORDERS” submenu.
3.17.2 Phase view
In this view voltage events are separated by phases. This is convenient view for troubleshooting.
Additionally, user can use filters in order to observe only particular type of event on a specific phase.
Captured events are shown in a table, where each line contains one phase event. Each event has an
