METREL MI 2893 User Manual

MI 2893 / MI 2892 / MI 2885 Temperature
68
3.11.1 Meter
Figure 49: Temperature meter screen
Table 41: Instrument screen symbols and abbreviations
0
C
Current temperature in Celsius degrees
0
F
Current temperature in Fahrenheit degrees
Table 42: Keys in Temperature meter screen
HOLD
Holds measurement on display. Hold clock time will be displayed in the
right top corner.
RUN
Runs held measurement.
METER
Switches to METER view.
TREND
Switches to TREND view (available only during recording).
Triggers Waveform snapshot.
Returns to the “MEASUREMENTS” submenu.
3.11.2 Trend
Temperature measurement TREND can be viewed during the recording in progress. Records containing
temperature measurement can be viewed from Memory list and by using PC software PowerView v3.0.
Figure 50: Temperature trend screen
Table 43: Instrument screen symbols and abbreviations
F1
F4
