MI 2893 / MI 2892 / MI 2885 Power
47
1 2 3  T
Shows measurement results for TOTAL power measurements.
METER
Switches to METER view.
TREND
Switches to TREND view (available only during recording).
Triggers Waveform snapshot.
Returns to the “MEASUREMENTS” submenu.
3.6.2 Trend
During active recording TREND view is available (see section 3.14 for instructions how to start GENERAL
RECORDER).
Figure 34: Power trend screen
Table 15: Instrument screen symbols and abbreviations
P1±, P2±,
P3±, Pt±
View: Combined power
Maximal ( ), average ( ) and minimal ( ) value of consumed (P
1
+
, P
2
+
, P
3
+
,
P
tot
+
) or generated (P
1
-
, P
2
-
, P
3
-
, P
tot
-
) active combined power for time interval
(IP) selected by cursor.
P1±, P2±,
P3±, P+±
View: Fundamental power
Maximal ( ), average ( ) and minimal ( ) value of consumed (Pfund
1
+
,
Pfund
2
+
, Pfund
3
+
, P+
tot
+
) or generated (Pfund
1
-
, Pfund
2
, Pfund
3
, P+
tot
-
) active
fundamental power for time interval (IP) selected by cursor.
Ni1±, Ni2±,
Ni3±, Nit±
View: Combined power
Maximal ( ), average ( ) and minimal ( ) value of consumed (N
1ind
+
, N
2ind
+
,
N
3ind
+
, N
totind
+
) or generated (N
1ind
-
, N
2ind
-
, N
3ind
-
, N
totind
-
) inductive combined
nonactive power for time interval (IP) selected by cursor.
Nc1±, Nc2±,
Nc3±, Nct±
View: Combined power
Maximal ( ), average ( ) and minimal ( ) value of consumed (N
1cap
+
, N
2cap
+
,
N
3cap
+
, N
totcap
+
) or generated (N
1cap
-
, N
2cap
-
, N
3cap
-
, N
totcap
-
) capacitive combined
nonactive power for time interval (IP) selected by cursor.
S1, S2, S3, Se
View: Combined power
Maximal ( ), average ( ) and minimal ( ) value of combined apparent power
(S
1
, S
2
, S
3
, Se
tot
) for time interval (IP) selected by cursor.
F4
