METREL MI 2893 User Manual

MI 2893 / MI 2892 / MI 2885 Power
48
S1, S2, S3, S+
View: Fundamental power
Maximal ( ), average ( ) and minimal ( ) value of fundamental apparent
power (Sfund
1
, Sfund
2
, Sfund
3
, S
+
tot
) for time interval (IP) selected by cursor.
PFi1±, PFi2±, PFi3±,
PFit±
View: Combined power
Maximal ( ), average ( ) and minimal ( ) value of inductive power factor (1
st
quadrant: PF
1ind
+
, PF
2ind
+
, PF
3ind
+
, PF
totind
+
and 3
rd
quadrant: PF
1ind
-
, PF
2ind
-
, PF
3ind
-
,
PF
totind
-
) for time interval (IP) selected by cursor.
PFc1±, PFc2±, PFc3±,
PFct±
View: Combined power
Maximal ( ), average ( ) and minimal ( ) value of capacitive power factor
(4
th
quadrant: PF
1cap
+
, PF
2cap
+
, PF
3cap
+
, PF
totcap
+
and 2
nd
quadrant: PF
1cap
-
, PF
2cap
-
,
PF
3cap
-
, PF
totcap
-
) for time interval (IP) selected by cursor.
Qi1±, Qi2±, Qi3±,
Q+i±
View: Fundamental power
Maximal ( ), average ( ) and minimal ( ) value of consumed (Q
1ind
+
, Q
2ind
+
,
Q
3ind
+
, Q
+
totind
+
) or generated (Q
1ind
-
, Q
2ind
-
, Q
3ind
-
, Q
+
totind
-
) fundamental reactive
inductive power for time interval (IP) selected by cursor.
Qc1±, Qc2±, Qc3±,
Q+c±
View: Fundamental power
Maximal ( ), average ( ) and minimal ( ) value of consumed (Q
1cap
+
, Q
2cap
+
,
Q
3cap
+
, Q
+
captot
+
) or generated (Q
1cap
-
, Q
2cap
-
, Q
3cap
-
, Q
+
captot
-
) fundamental reactive
capacitive power for time interval (IP) selected by cursor.
DPFi1±,
DPFi2±,
DPFi3±
DPF+it±
View: Fundamental power
Maximal ( ), average ( ) and minimal ( ) value of inductive displacement
power factor (1
st
quadrant: DPF
1ind
+
, DPF
2ind
+
, DPF
3ind
+
, DPF
totind
+
, and 3
rd
quadrant: DPF
1ind
-
, DPF
2ind
-
, DPF
3ind
-
DPF
totind
-
,) for time interval (IP) selected by
cursor.
DPFc1±,
DPFc2±,
DPFc3±
DPF+ct±
View: Fundamental power
Maximal ( ), average ( ) and minimal ( ) value of capacitive displacement
power factor (4
th
quadrant: DPF
1cap
+
, DPF
2cap
+
, DPF
3cap
+
, DPF
totcap
+
, and 2
nd
quadrant: DPF
1cap
-
, DPF
2cap
-
, DPF
3cap
-
, DPF
totcap
+
) for time interval (IP) selected by
cursor.
Sn1, Sn2,
Sn3, Sen
View: Nonfundamental power
Maximal ( ), average ( ) and minimal ( ) value of consumed or generated
nonfundamental apparent power (Sɴ
1
, Sɴ
2
, Sɴ
3
, Seɴ
tot
) for time interval (IP)
selected by cursor.
Di1, Di2,
Di3, Dei
View: Nonfundamental power
Maximal ( ), average ( ) and minimal ( ) value of consumed or generated
phase current distortion power (Dı
1
, Dı
2
, Dı
3
, Deı
tot
) for time interval (IP)
selected by cursor.
Dv1, Dv2,
Dv3, Dev
View: Nonfundamental power
Maximal ( ), average ( ) and minimal ( ) value of consumed or generated
phase voltage distortion power (Dv
1
, Dv
2
, Dv
3
, Dev
tot
) for time interval (IP)
selected by cursor.
Ph1±, Ph2±, Ph3±,
Pht±
View: Nonfundamental power
Maximal ( ), average ( ) and minimal ( ) value of consumed (P
H1
+
, P
H2
+
, P
H3
+
,
P
Htot
+
) or generated (P
H1
-
, P
H2
-
, P
H3
-
, P
Htot
-
) active harmonic power for time
interval (IP) selected by cursor.
Table 16: Keys in Power (TREND) screens
