MI 2893 / MI 2892 / MI 2885 General Setup submenu
125
Figure 94: Transient setup screen – MI 2892/MI 2885
Note:
MI 2893 – all triggers could be activated at the same time
MI 2892/MI 2885 - only one trigger is available: Envelope: U or U
n
or I or I
n
; Level: U or U
n
or I or I
n
Table 108: Description of Transient setup
Show triggering help screens. See 5.1.20 for details.
Deleting the trigger selection.
Check connection settings. See 3.23.1 for details.
3.24 General Setup submenu
From the “GENERAL SETUP” submenu communication parameters, real clock time, language,
lock/unlock and colour model can be reviewed, configured and saved.
Figure 95: GENERAL SETUP submenu
