Installing the Printer and the intelligent Paper Stacker
1-2
– Air circulation
In general there are no restrictions concerning air circulation. However, it is to be
observed that the air flow does not move the fanfold paper heavily at the paper
entry and paper exit of the printer and such may lead to paper jams.
In conjunction with the paper stacking system care has to be taken that the air flow
does not disturb a proper operation of the stacker.
– Impact of Light and Sunshine
Since the printer is equipped with a light-sensitive photoconductor drum and
optical sensors it shall in generally not be installed at a location which is exposed
to sunlight. If not otherwise possible window shades have to provide for the
necessary protection.
Note: The printer must never be installed such that its right side (paper exit)
points to a window.
If the top cover is opened to clear a paper jam or to perform maintenance actions
sunbeams would directly fall onto the photoconductor drum and would
permanently destroy its surface after an impact period of about 1 minute.
– Acoustical noise
The upper limits of the acoustical noise are shown below.
– Print operation: < 60 dB(A)
– Stand-by: < 48 dB(A)
– Power dissipation
If an interruption of a print operation occurs the printer can enter the Power Save
mode when for a certain period of time whose duration is selected at the operator
panel the printer does not perform any further operation. In this mode most of the
printer´s subsystems are disconnected from power. The operating mode is
resumed when the printer receives further data from the host system.
Mode Power consumption
Operating
< 800 Watt average
< 1.300 Watt max.
Stand-by
< 110 Watt average
< 1.200 Watt max.
Sleep mode
(power save
)
< 45 Watt average
