Microplex SOLID F90 HD - Pre-Charger Replacing

118 Operator Maintenance
_______________________________________________________________________________________________
________________________________________________________________________________________________
MICROPLEX Operator’s Manual SOLID F90 HD Edition 1.0
7.5. Pre-Charger Replacing
After having printed 636,000 pages A4 (portrait Two-U
p) the pre-
charger has to be replaced.
Turn off the printer and pull the power plug before start working at
the chargers.
1. Open the front cover of the printer.
2. Open the waste toner recovery unit.
Waste toner recovery unit
Open lever (green)
3. Turn to loosen the green knurled screw of the pre-charger and
pull the pre-charger out towards you.
Pre
-
charger
Green knurled
screw
