Microplex SOLID F90 HD - _______________________________________________________________________________________________

34 Operation and Menu Structure
_______________________________________________________________________________________________
________________________________________________________________________________________________
MICROPLEX Operator’s Manual SOLID F90 HD Edition 1.0
Control Panel Keys
ON LINE
FORM
LENGTH
!
LINE
FEED
FORM
FEED
SPLI
T
This sy
mbol shows the ON LINE key. This key is used to turn the
printer ON LINE or OFF LINE.
The other control panel keys are only active in the OFF LINE mode.
The current form length is announced. The
form lengths from 7 to
20 inches can be selected in 1/6 inch steps.
The cutting device can only cut paper along the perforation, so
the set form length has to correspo
nd with the current paper size.
Wrong settings lead to paper jams.
Paper will be transported 1/6 inch forward.
After loadin
g new paper the paper will be driven to the start
position. Apart from that activating the FORM FEED key in the OFF
LINE mode will move the paper one form length ahead.
The last print job will be cut at its end and the paper will be moved
to the park position.
