Microplex SOLID F90 HD - Pre-Charger Cleaning

100 Operator Maintenance
_______________________________________________________________________________________________
________________________________________________________________________________________________
MICROPLEX Operator’s Manual SOLID F90 HD Edition 1.0
7.1.2. Pre-Charger Cleaning
Turn off the printer and pull the power plug before start working at
the chargers.
1. Open the front cover of the printer.
2. Press down the open lever to open the waste toner recovery unit.
Waste toner recovery unit
Open lever (green)
3. Loosen the knurled screw of the pre-charger and pull out the
charger.
Pre-charger Knurled screw
