MICROPLEX Operator’s Manual SOLID F90 HD Edition 1.0
10. Specifications
Print technology:
Print speed:
(max.)
Resolution:
Paper weight:
Paper size:
Stacker:
Interfaces:
Size:
Weight:
Environment:
Mains connection:
Power admission:
maximum
permissible system
impedance Z
max
:
non-impact/electrophotographic, LED, OPC, Xenon-lamp flash fusing
85 pages per minute (A4 portrait Two-Up)
300 dpi /600 dpi (in each case dots per inch horizontal and vertical)
60 - 204 g/m²
Width:
6 to 18 inches (appr.152 to 457 mm), 17 inches printable *)
Length: 7 to 24 inches (appr.178 to 610 mm)
8 to 14 inches (using the stacker)
3000 sheets (64 g/m² ; 8 to 14 inches) inside the stacker
parallel: IEEE 1284 (Centronics), (MP-BUS, SPS-Control, optional)
LAN: Ethernet 10/100 Mbit (TCP-IP)
Optional:
LAN: Ethernet (SPX-IPX, LAT), Token Ring
Host: IBM SCS / IPDS (Twinax/Coax), Siemens (BAM/SS-97)
780mm (W) x 1320mm (H) x 890mm (D); incl. stacker 935mm (T)
appr. 275 kg (including the stacker)
Temperature: +15°C to +30°C (59°F to 86°F) (operating)
-10°C to +35°C (14°F to 95°F) (non operating)
Rel. atmospheric humidity: 30% to 80 % (operating)
10% to 80 % (non operating)
230 V +/-- 10% AC, 50 Hz Europe, United Kingdom e.g.
max. appr. 5.5 kVA effective
(max. 0.6 kVA standby)
appr. 0.02 Ohm
*) Hint: Fanfold material cannot be printed in the area of the sprocket holes, even in the
distance up to 5mm around the sprocket holes a reduced print quality has to be
expected.
