MICROPLEX Operator’s Manual SOLID F90 HD Edition 1.0
5.16. Transparent Code Adjustment
This function configures the transparent code. Using the transparent
code enables you to initiate the commands of the page description
language IDOL by
printable characters. The transparent code pre-
setting is 2625. These are the ASCII character codes (hexadecimal)
for the characters
& % (ref. IDOL Programming Manual).
ON LINE
SAVE
SAVE
SAVE
MENU
SAVE
ON LINE
Panel display
[SOLID F90 HD ]
[Menu Level 1 ]
( ( (
[Configuration ]
[Interface ]
( ( (
[Transparent Code ]
[Digit4 2
625]
( ( (
[Digit1 2626
]
[Save as Setup? ]
Notes
Turn the printer OFF LINE with this key.
Press one of the ARROW keys until
[Configurat
ion ] is displayed.
Press one of the ARROW keys until
[Transparent Code ] is displ
ayed.
The hexadecimal numbers for
& % are
preset.
Pressing one of the ARROW keys
changes the value of the current digit
(Digit4 = left position, in this example: 2).
Pressing the SAVE key moves you to the
next digit (the MENU key moves you back).
2626 is selected as transparent code.
From now on use the characters
& &
before programming the IDOL commands.
In addition this new value can be saved as
setup value
(using the SAVE key), before
the printer is turned ON LINE again.
