5 - 8 046-003777-00 A5/A3™ Operating Instructions
5.6 Ventilation Modes
NOTE: In all ventilation modes, when inspiration pressure reaches the high
alarm limit of Paw, the system switches to expiration immediately and
airway pressure is released.
NOTE: When the drive gas supply fails, mechanical ventilation cannot work
normally.
5.6.1 Monitored Parameters
NOTE: The monitored parameters are measured in the condition of ATPS
(ambient temperature and pressure saturated).
The A5/A3 monitors the following ventilation parameters:
5.6.2 Ventilation Modes
The A5/A3 provides the following ventilation modes:
5.6.3 Change Ventilation Mode
To change ventilation mode to Manual
1. Use the Auto/Manual Bag switch on the breathing system block to enter and exit Manual
ventilation mode.
PARAMETER RANGE* COMMENTS
PEAK -20 –120 cmH
2
O
MEAN -20 – 120 cmH
2
O
Vt 0 – 3000 ml
MV 0 – 100 L
PLAT -20 – 120 cmH
2
O
Rate 0 – 120 bpm
PEEP 0 – 70 cmH
2
O
FiO
2
18 – 100%**
I:E — Displayed only in SIMV-VC, SIMV-PC, and PS modes
* If the monitored parameter is out of range, it will be displayed as “- - -”.
**FiO
2
measurements between 100% and 110% inclusive will be displayed as 100%. Above this range, the system
will display “- - -”.
VENTILATION MODE PARAMETERS
VCV Vt, Rate, I:E, Tpause, PEEP, Plimit
SIMV-VC Vt, Rate, Tinsp, Tpause, PEEP, Plimit, PS (On/Off), ΔP, Tr i g g er, Ts l o p e,
PCV A5: VtG, PlimVG, Pinsp, Rate, I:E, PEEP, Tslope
A3: Pinsp, Rate, I:E, PEEP, Tslope
SIMV-PC (A5 only) Pinsp, Rate, Tinsp, PS (On/Off), ΔP, Tr i g g e r, P EE P, Ts l o p e
PS Min Rate, ΔP, Trigger, PEEP, Tslope, Apnea Ti
Manual Bypass (A5 only), Alarms, Monitor (available with AG module)
