A5/A3â„¢ Operating Instructions 046-003777-00 9 - 7
Product Specifications Electrical Specifications
9.6 Electrical Specifications
9.6.1 Main Electrical Power Specifications
The A5/A3 complies with IEC 60601-1 for its main power supply.
9.6.2 Battery Power Specifications
9.6.3 Auxiliary Electrical Outlets
Power Supply Input Voltage: 100 to 120 VAC @ 60 Hz
Power Supply Input Current: 12 A maximum (2A maximum for A5 unit. 10 A maximum for
A5 auxiliary outlets)
12 A maximum (3A maximum for A3 unit. 9 A maximum for
A3 auxiliary outlets)
Power Cord: 5 ± 0.05 m (length), hospital grade
TABLE 9-5 Main Electrical Power Specifications
Battery Type: Sealed Lithium-ion, 11.1 V, 4.5 Ah
A5: two (2) batteries
A3: one (1) battery
Battery Run-time: One (1) new battery installed: > 75 minutes
Two (2) new batteries installed: > 150 minutes
Run-time criteria: VCV mode (Tv = 500 ml, Rate = 10 bpm, I:E
= 1:2, Plimit = 30 cmH
2
O, PEEP = OFF)
Time to Shutdown from
Lower Battery Alarm:
> 5 minutes (new fully-charged battery supply)
Battery Charge Time: New Battery: < 8 hours from an initial charge of 10 %
Charging occurs whenever AC is applied to the A5/A3
System.
TABLE 9-6 Battery Power Specifications
Number of Outlets: A5: 4
A3: 3
Output Voltage: 100 to 120 VAC @ 60 Hz (corresponds to power supply input
voltage)
Output Current of Each Auxiliary Outlet: 3 A
Output Current Total: A5: 10 A
A3: 9 A
Breaker Rating per Auxiliary Outlet: 3 A
Breaker Rating Total: A5: 10 A
A3: No total current breaker
TABLE 9-7 Auxiliary Electrical Outlets
