A5/A3â„¢ Operating Instructions 046-003777-00 9 - 5
Product Specifications Physical Specifications
9.3 Physical Specifications
9.4 Stability Configurations and Conditions
Maintains stability when tilted 10 degrees, as required by IEC 60601-1, clause 9.4.
WARNING: Due to the size and weight of the A5/A3, it should only be moved by
qualified personnel.
WARNING: To avoid tip hazards, use care when moving the A5/A3 up or down
inclines, around corners and across thresholds. Remove all equipment
from the top shelf and mounted to the side of the A5/A3 before moving.
Do not attempt to roll the A5/A3 over hoses, cords or other obstacles.
Dimensions: Height: 1400 mm ± 25 mm
Width: 1050 mm ± 25 mm
(including breathing system)
Depth: 805 mm ± 25 mm
Weight
(no vaporizers or gas cylinders):
A3: 150 kg (331 lbs) ± 5 kg
A5: 160 kg (353 lbs) ± 5 kg
Work Surface
(stainless steel):
Width: 616 mm (24.3 in) ± 25 mm
Depth: 380 mm (15.0 in) ± 25 mm
Height: 850 mm (33.5 in) ± 25 mm
Top Shelf: Weight Capacity: 40 kg (88.2 lbs)
Width: 616 mm (24.3 in) ± 25 mm
Depth: 362 mm (14.3 in) ± 25 mm
Dimensions of the mounting holes:
Length: 258 mm ± 0.3 mm
Width: 150 mm ± 0.3 mm
Depth of the mounting hole: 11.5 mm
The screw type: M4
Side Mounting Rails: Supporting weight: 25 kg at a maximum distance of 0.41 m
Bag Arm: Fixed Height Bag Arm:
Length: 312 mm ± 10 mm
Height: 1150 mm ± 10 mm
Swiveling angle: 150 ± 10 degrees
Flexible Bag Arm:
Length: 550mm ± 10mm
The height and angle of the flexible bag arm can be adjusted freely.
Drawers
(internal dimensions):
Drawers are of equal size:
• Height: 135 mm ± 10 mm
• Width: 440 mm ± 10 mm
• Depth: 385 mm ± 10 mm
Casters: Diameter: 15 cm (6 in)
Brake:
• A5 model: central brake with lock/unlock indicator
• A3 model: individual caster brakes
Cable pusher: cable pusher with each caster
Handle Length: 650 mm ± 25 mm
TABLE 9-3 Physical Specifications
