Mindray A5 Operating Instructions

Anesthetic Gas Scavenging System (AGSS) Product Specifications
9 - 14 046-003777-00 A5/A3™ Operating Instructions
9.9 Anesthetic Gas Scavenging System (AGSS)
9.10 Monitor Module
9.10.1 AG Module
Type of the Applicable
Disposable System:
Low flow
Size: 430 mm x 132 mm x 114 mm
Tolerance: +/- 5 mm
Weight 2.15 kg +/- 0.05 kg
Extract Flow: 25 to 50 L/min
Resistance: ≤ 0.35 kPa @ 75 L/min
TABLE 9-20 Anesthetic Gas Scavenging System (AGSS)
Measurement mode: Sidestream
Warm-up time: ISO accuracy mode: < 45 s
Full accuracy mode: < 10 min
Sampling rate: Sampling rate:
120/150/200 ml/min: High Volume AG Watertrap
70/90/120 ml/min: Low Volume AG Watertrap
Accuracy: ± 10 ml/min or ± 10 %, whichever is greater
Emptying interval (half full, worst case): High volume AG watertrap: 17h @ 200 mL/min,
37°C, 100% RH
Low volume AG watertrap: 20h @ 120 mL/min,
37°C, 100% RH
Gas: CO
2
, O
2
(Paramagnetic O
2
module), N
2
O, and any of the five
anesthetic agents: DES, ISO, ENF, SEV and HAL.
Range: CO
2
: 0 to 30 %
O
2
: 0 to 100 %
N
2
O : 0 to 100 %
DES : 0 to 30 %
SEV : 0 to 30 %
ENF : 0 to 30 %
ISO : 0 to 30 %
HAL : 0 to 30 %
ISO accuracy mode As Full accuracy specifications, but derated as follows:
Add ± 0.3 %
ABS
to accuracy for CO
2
;
Add ± 8 %
REL
to accuracy for all agents;
N
2
O accuracy is ± (8 %
REL
+ 2 %
ABS
).
1): 10 % to 90 %. Sample gas flow: 200 ml/min. DRYLINE
TM
watertrap. Adult DRYLINE
TM
sampling line (2.5 m).
2): 10 % to 90 %. Sample gas flow: 120 ml/min. DRYLINE
TM
watertrap. Pediatric DRYLINE
TM
sampling line (2.5 m).
TABLE 9-21 AG Module

Mindray A5 Specifications

General

Type	Anesthesia Machine
Brand	Mindray
Model	A5
Power Supply	100-240 V AC, 50/60 Hz
Ventilation Modes	SIMV, PSV
Flowmeters	O2, N2O, Air
Vaporizer Capacity	Up to 3 vaporizers
Safety Features	O2 failure protection, low pressure alarm
Gas Module	Optional integrated gas module
Integrated Air Compressor	Optional
Patient Monitoring	Integrated monitoring with optional modules
