Mindray A5 Operating Instructions

Cleaning and Disinfection Maintenance
7 - 22 046-003777-00 A5/A3™ Operating Instructions
7.10.10 Absorber Canister
1. Locate the condensate drain valve at the bottom of the absorber canister assembly.
FIGURE 7-17 Condensate Drain Valve Location
FIGURE 7-18 Condensate Drain Valve (Close Up View)
2. While holding a small cup below the drain, turn the condensate drain valve clockwise to
open the drain and collect any water that may have gathered. Turn the drain valve counter-
clockwise to close the drain. Discard any water collected.
WARNING: Use extreme care while handling the absorbent as it contains a caustic
irritant.
3. Rotate the locking mechanism handle clockwise into the unlocked position (see FIGURE 7-
19). This separates the absorber canister from the top of the assembly. While noting the
previous WARNING, remove the absorber canister. Then remove the Pre-Pak or loose fill
absorbent from the canisters. Dispose of the absorbent as per the local regulations.
Absorber Canister
Condensate Drain
Turn the condensate
drain valve to open
and close

Mindray A5 Specifications

General

Type	Anesthesia Machine
Brand	Mindray
Model	A5
Power Supply	100-240 V AC, 50/60 Hz
Ventilation Modes	SIMV, PSV
Flowmeters	O2, N2O, Air
Vaporizer Capacity	Up to 3 vaporizers
Safety Features	O2 failure protection, low pressure alarm
Gas Module	Optional integrated gas module
Integrated Air Compressor	Optional
Patient Monitoring	Integrated monitoring with optional modules
