Mindray A5 Operating Instructions

Ventilation Parameter Relationships Parameters and Factory Defaults
C - 16 046-003777-00 A5/A3™ Operating Instructions
NOTE: Even when the PlimVG, Pinsp, or ΔP parameters are inactive, they are
restricted to the parameter relationship equations.
PCV Rate
4 ≤ Rate ≤ 100
VtG If VtG is not Off.
20 ≤ Vt ≤ 1500
Pinsp
(A5 only)
Pinsp ≥ PEEP+5
5 ≤ Pinsp ≤ 70
PlimVG
(A5 only)
PlimVG ≥ PEEP+5
5 ≤ PlimVG≤ 100
SIMV-PC
(A5 ONLY)
Rate
4 ≤ Rate ≤ 100
Pinsp Pinsp ≥ PEEP+5
5 ≤ Pinsp ≤ 70
VENTILATION
MODE Parameter
Parameter
Relationship Equation (s)

Mindray A5 Specifications

General

Type	Anesthesia Machine
Brand	Mindray
Model	A5
Power Supply	100-240 V AC, 50/60 Hz
Ventilation Modes	SIMV, PSV
Flowmeters	O2, N2O, Air
Vaporizer Capacity	Up to 3 vaporizers
Safety Features	O2 failure protection, low pressure alarm
Gas Module	Optional integrated gas module
Integrated Air Compressor	Optional
Patient Monitoring	Integrated monitoring with optional modules
