Pneumatic Diagram Pneumatic Diagram of the A5/A3 System
NO. DESCRIPTION NO. DESCRIPTION
1. O
2
Gas Pipeline Connection 33. Bypass Valve
2. O
2
Gas Cylinder Connection 34. O
2
Sensor
3. N
2
O Gas Pipeline Connection 35. Airway Pressure Gauge
4. N
2
O Gas Cylinder Connection 36. Inspiratory Flow Sensor
5. Air Gas Pipeline Connection 37. Patient Connector
6. Air Gas Cylinder Connection 38. Expiratory Flow Sensor
7. Gas Cylinder Pressure Regulator (360
kPa)
39. Watertrap
8. Pressure Relief Valve (758 kPa) 40. Expiratory Check Valve
9. Drive Gas Inlet Filter 41. Auto/Manual Bag Switch
10. Pressure Regulator (200 kPa) 42. Breathing Bag
11. Inspiratory Flow Control Valve 43. APL Valve
12. Inspiratory Flow Sensor 44. Auxiliary O
2
Gas Power Outlet
13. Safety Valve (110 cmH
2
O) 45. Bellows
14. Pop-off Valve 46. Pressure Relief Valve (1kPa, 10 cmH
2
O)
15. PEEP Safety Valve 47. Negative Pressure Check Valve (1 cmH
2
O)
16. Drive Gas Pressure Switch (140 kPa) 48. Gas Container
17. PEEP Proportional Valve 49. Pressure Sensor
18. Exhaust Valve 50. Total Flowmeter
19. Flow Restrictor 51. Auxiliary Oxygen Flowmeter
20. O
2
Flush Valve 52. Negative Pressure Check Valve
21. Flow Restrictor 53. Pressure Sensor
22. O
2
Pressure Switch (220 kPa) 54. AGSS
23. Pressure Regulating Valve (200 kPa) 55. Check Valve
24. System Switch 56. Back Pressure Valve
25. Oxygen Ratio Controller (ORC) 57. Flow Compensation Valve
26. Flow Control and Electronic Display
Module
58. Venturi Generator
27. Dual Vaporizer Block 59. Muffler
28. Check Valve 60. Negative Pressure Regulator
29. Pressure Relief Valve (37.9 kPa) 61. Negative Pressure Gauge
30. Auxiliary Air Flowmeter 62. Floating Overfill Protection Valve
31. Inspiratory Check Valve 63. Filter
32. Sodalime Absorber Canister 64. AG Watertrap
