Attention Symbols Abbreviations, Symbols, and Units of Measure
E - 6 046-003777-00 A5/A3â„¢ Operating Instructions
ATTENTION!
NUMBER DESCRIPTION
01 Total Flowmeter: The total flowmeter is calibrated based on 100 % O
2
. The accuracy of
the flowmeter may degrade with other gas or mixed gas.
When viewing the readings on the total flowmeter, keep your visual angle at the same
level of the float. The reading of the scale may vary when viewed at a different angle.
If the readings shown on the electronic flowmeters differ from that on the total
flowmeter, the electronic flowmeter will prevail and the total flowmeter is an
approximate value.
02 Only vaporizers with Selectatec Interlock-Systems may be used with the A5/A3 unit.
Use vaporizers compliant to ISO 80601-2-13. See sectionA.9 (page A-4) "Vaporizers".
Refer to the vaporizer manufacturer’s Instructions For Use for filling or draining the
vaporizer and other information.
Use care in lifting and manipulating vaporizers during the mounting process as their
weight may be greater than expected, based on their size and shape.
