Physical Views Product Description
1 - 10 046-003777-00 A5/A3™ Operating Instructions
A4 Auxiliary O
2
/Air Gas Outlet Nozzle (barbed connector) for auxiliary O
2
/Air output.
Combines the auxiliary O
2
/Air flowmeters into a single
output of O
2
only, Air only, or O
2
/Air blend, depending
upon the O
2
and Air flow adjustments.
A5 Auxiliary O
2
Gas Power Outlet
(A5 only)
High pressure O
2
outlet (DISS connector) for connecting
external devices such as a jet ventilator.
A6 Flow Control Knobs N
2
O, Air, and O
2
gas dosing. Turn each knob
counterclockwise to increase flow.
A7 Pressure Gauges (pipeline) Indicate the pressure at pipeline inlets for O
2
, Air, and N
2
O.
A8 Pressure Gauges (cylinder) Indicate the pressure at cylinder inlets for O
2
, Air, and N
2
O.
A9 Total Flow Meter Displays the combined flow rate of O
2
, Air, and N
2
O.
A10 O
2
Sensor Electrical Port Connects the O
2
sensor cable on the breathing system to
the main A5/A3 unit.
A11 O
2
Flush Button Provides high flow O
2
to the inspiratory limb of the
breathing system.
A12 Vacuum suction fixing clip Holds the tubes of the negative pressure suction device.
A13 Touchp ad
(A5 only)
Allows alternative control of the touch screen. Pull out to
use.
A14 AGSS Anesthetic Gas Scavenging System.
A15 Wheel Lock
(A5 only)
Locks or releases the brakes for all wheels when depressed.
A16 Wheel Lock Indicator
(A5 only)
Displays a lock symbol in red background to indicate the
wheels are locked, or an unlock symbol in green
background to indicate the wheels are unlocked.
A17 Wheels Casters to enable the A5/A3 System to be moved. Casters
on the A5 lock via a central brake. Casters on the A3 lock via
individual locking levers on each caster.
A18 Work Light Located under the top shelf to illuminate the work level
shelf and allow the user to read the vaporizer dial setting in
a dim light room.
A19 Work Light Switch Turns on/off the work light. Three settings: Off, Low, and
High.
The user can turn on the work light only when the
system switch is turned on.
A20 Vaporizer Mounting Manifold /
Mounting Bar
An interface for two/three Selectatec-type vaporizers to
mount in this location. Bar holds two/three (optional)
vaporizers. An interlock within the vaporizers provides for
use of one vaporizer to deliver one agent at a time.
A21 Vaporizer Mount Valve
Cartridge
Vaporizer index and outlet ports.
A22 Vaporizer Parking Spot Holds a non-functional vaporizer for user convenience.
(A5 standard, A3 optional)
A23 Vaporizer Locking Device Vaporizer locking mechanism to secure against accidental
disconnection
A24 AC Status LED Illuminated when the system is connected to an AC power
source.
A25 Battery Charging LED Illuminated when the battery supply is charging.
A26 System Switch Switch to turn the system on or off.
A27 Handle Metal bar used to assist moving the A5/A3
PART(S) DESCRIPTION
