Physical Views Product Description
1 - 12 046-003777-00 A5/A3â„¢ Operating Instructions
B3 Exhaust Fan Forces air to cool electronics and prevent buildup of O
2
concentration. Do not block.
B4 Communication Ports SP1, DP1, CS1, SB1, SB2 (see section9.6.4 (page 9-8)
"Communication Ports".)
CAUTION: Do not connect any
devices to the SB ports
other than Mindray
approved USB storage
devices and a supported
USB mouse (see
‘‘Networking and USB
Storage’’ on page A-4).
B5 Auxiliary AC Outlets A5: Additional devices up ‘to a total maximum power of 10
amps can be connected to four (4) outlets.
A3: Additional devices up to a total maximum power of 9
amps can be connected to three (3) outlets.
The A5 outlets are covered with two (2) metal plates, the A3
outlets are covered with one (1) metal plate, and require a
tool to access. Only authorized personnel can access these
outlets.
B6 Equipotential stud / lug Provides a ground point. Eliminates the ground potential
difference between different devices to ensure safety.
B7 Hooks Allows user to hang or wrap cords
B8 Cylinder Supply Connections Interface connectors to high pressure supply tanks (O
2
, Air,
and N
2
O)
B9 Gas Pipeline Supply
Connections
Connections for O
2
, Air, and N
2
O from a pipeline gas supply
B10 Sample Line Exhaust Gas Inlet Inlet for exhaust gas from gas module. Merges with the
AGSS connector that connects to the AGSS.
B11 Waste Gas Scavenging
Connector
Connects the active AGSS (AGSS or DGSS), or passive AGSS.
B12 AGSS Anesthetic Gas Scavenging System.
B13 Cylinders Supply tanks (E-size) containing high pressure O
2
, Air, and
N
2
O to act as backup supply if the pipeline pressure is
removed. Note: Tanks not supplied by Mindray.
B14 Waste Gas Transfer Hose Routes exhaust gases from main unit to scavenger.
PART(S) DESCRIPTION
