5-38 Image Optimization
5.10.3.2 Static 3D Acquisition Preparation
îš„ Parameters description:
Type Parameter Description
Parameter
adjusting
Angle
Function: to set the range for imaging.
Range: 10-70°, in increments of 5°.
Quality
Function: to adjust the image quality by changing the
line density. Image quality can affect the imaging speed
that the better the image quality, the longer the time.
Range: Low2, Low1, Mid, High1, High2.
Render Mode
Surface
Function: set Surface as 3D image rendering mode.
This is helpful for surface imaging, such as fetus
face/hand or foot.
Tips: you may have to adjust the threshold to obtain a
clear body boundary.
Max
Function: set Max as 3D image rendering mode,
displays the maximum echo intensity in the observation
direction.
This is helpful for viewing bony structures.
Min
Function: set Min as 3D image rendering mode,
displays the minimum echo intensity in the observation
direction.
This is helpful for viewing vessels and hollow structures.
X-ray
Function: set X-ray as 3D image rendering mode.
Displays the average value of all gray values in the ROI.
X Ray: used for imaging tissues with different structure
inside or tissues with tumor.
