Image Optimization 5-43
îš„ Render Mode
Parameter Description
Gray/Inversion
Surface
Function: set Surface as 3D image rendering mode.
This is helpful for surface imaging, such as fetus
face/hand or foot.
Tips: you may have to adjust the threshold to obtain a
clear body boundary.
Max
Function: set Max as 3D image rendering mode,
displays the maximum echo intensity in the observation
direction.
This is helpful for viewing bony structures.
Min
Function: set Min as 3D image rendering mode,
displays the minimum echo intensity in the observation
direction.
This is helpful for viewing vessels and hollow
structures.
X-ray
Function: set X-ray as 3D image rendering mode.
Displays the average value of all gray values in the
ROI.
X Ray: used for imaging tissues with different structure
inside or tissues with tumor.
The above four rendering manners can be applied to both gray and
inversion modes.
Where, inversion is to inverse the grayscale of the image, so as to
enhance observation for low-echo region, applicable for vessel, cyst
and etc.
When the function is turned on, the rendering mode parameters
change into the corresponding inverse parameters.
