Mindray DC-N3S

Probes and Biopsy 13-9
Refer to the following table of all probe dimensions to choose the necessary probe
sheath type.
Model Length(mm) Width(mm) Height(mm) Cable Length(mm)
3C5A 114.7 75.9 29.8 2260±50mm
V10-4 315.84 40.95 31.85 2260±50mm
V10-4B 323 32.25 31.01 2260±50mm
6C2 95 33.5 24.8 2260±50mm
7L4A 101.6 61 25.7 2260±50mm
L11-4 101.6 61 25.7 2260±50mm
L12-4 101.6 61 25.7 2260±50mm
L14-6 91.4 47.1 22.8 2260±50mm
2P2 102.7 38.1 30.4 2260±50mm
D6-2 117.4 68.36 44.99 2260±50mm
D6-2A 128.0 79.0 56.0 2260±50mm
P7-3 79.5 34 25.2 2260±50mm
L7-3 102 61.1 25 2260±50mm
CW5s 105 13.7 13.7 2260±50mm
7L5 102.4 69.7 25.9 2260±50mm
L14-6N 101.6 61 25.7 2260±50mm
CB10-4 324.3 38.8 34.5 2260±50mm
