Probes and Biopsy 13-27
(3) Check manually to confirm that the needle-guided bracket is securely installed
on the probe.
(4) Select a proper guiding block and push it into the groove above the angle block,
and clamp it tightly.
(5) Insert a biopsy needle with the same specification as that of the guiding block
into the hole of the guiding block.
îš„ NGB-011
(1) Inosculate the locating groove on the clamp with the two raised edges on the
probe head and align the locating pit of the clamp to the convex point on the
probe head.
(2) Turn the grip knob at the tail of the needle-guided bracket tightly.
îš„ NGB-016
(1) Put on the probe sheath.
(2) Select a proper needle-guided bracket, and match the groove with the tab of the
probe. Mount the bracket onto the probe.
To Next Page
