Mindray uMEC12 Operator's Manual

14-4
WARNING
z If measuring intracranial pressure (ICP) with a sitting patient, level the transducer
with the top of the patient’s ear. Incorrect leveling may give incorrect values.
14.5 Understanding the IBP Display
The IBP measurement is displayed on the monitor as a waveform and numeric pressures. The
figure below shows the waveform and numerics for the Art pressure. For different pressures,
this display may be slightly different.
(1) Waveform
(2) Pressure unit
(3) Systolic pressure
(4) Diastolic pressure
(5) Mean pressure
For some pressures, the parameter window may show the mean pressure only. For different
pressures, their defaults unit may be different. If the Art and ICP pressures are measured
simultaneously, the ICP parameter area will display numeric CPP, which is obtained by
subtracting ICP from the Art mean.
(1)
(3) (5)(4) (2)

Mindray uMEC12 Specifications

General

Type	Patient Monitor
Display	12.1-inch color TFT
ECG	3-lead
SpO2	Yes
NIBP	Yes
Respiration	Yes
Temperature	Yes
Battery	Rechargeable lithium-ion
Networking	Ethernet
Parameters	ECG, SpO2, NIBP, Respiration, Temperature
Connectivity	Ethernet
Battery Life	Up to 4 hours
Power Supply	100-240 VAC, 50/60 Hz
