Mindray uMEC12 Operator's Manual

16-3
16.5 Measuring CO
2
16.5.1 Making a CO
2
Measurement
1. Select the appropriate watertrap and sampling line according to the patient category.
2. Connect the watertrap and sampling line.
 If you use DRYLINE II watertrap (PN: 100-000080-00 or PN: 100-000081-00),
connect the watertrap to the watertrap receptacle, and then connect the sampling
line to the watertrap as shown below.
 If you use DRYLINE PRIME watertrap mini, connect the DRYLINE PRIME
receptacle to the watertrap receptacle, connect the DRYLINE PRIME watertrap
mini to the DRYLINE PRIME receptacle adapter, and then connect the DRYLINE
PRIME sampling line to the watertrap mini as shown below.
Watertrap receptacle
DRYLINE II watertrap
Sampling line
DRYLINE PRIME
sampling line
DRYLINE PRIME
receptacle adapter
DRYLINE PRIME
watertrap mini
Watertrap trap receptacle

Mindray uMEC12 Specifications

General

Type	Patient Monitor
Display	12.1-inch color TFT
ECG	3-lead
SpO2	Yes
NIBP	Yes
Respiration	Yes
Temperature	Yes
Battery	Rechargeable lithium-ion
Networking	Ethernet
Parameters	ECG, SpO2, NIBP, Respiration, Temperature
Connectivity	Ethernet
Battery Life	Up to 4 hours
Power Supply	100-240 VAC, 50/60 Hz
