8-9
Set notch frequency according to the electric power frequency of your country. Follow this
procedure:
1. When [Notch Filter] is set on, select [Main Menu][Maintenance >>][User
Maintenance >>]enter the required password.
2. Select [Others >>][Notch Freq.] and then select [50Hz] or [60Hz] according to the
power line frequency.
8.5.7 Changing the Pacer Reject Settings
Select [ECG Setup][Others>>][Pacer Reject], and toggle between [On] and [Off].
When [Paced] is set to [Ye s]:
When [Pacer Reject] is switched on, the pace pulses are not counted as extra QRS
complexes.
The pace pulse marks “|” are shown on the ECG wave when pace pulses are detected.
When [Paced] is set to [No], the pace markers are not shown on the ECG wave, and the
options of [Pacer Reject] are invalid.
8.5.8 Changing ECG Wave Settings
In the [ECG Setup] menu:
You can select [ECG], [ECG1], or [ECG2] to select a lead to view. The waveform of
selected lead should have the following characteristics:
The QRS should be either completely above or below the baseline and it should not
be biphasic.
The QRS should be tall and narrow.
The P-waves and T-waves should be less than 0.2mV.
If the wave is too small or clipped, you can change its size by selecting an appropriate
[Gain] setting. If you select [Auto] from [Gain], the patient monitor will automatically
adjust the size of the ECG waves. In normal screen, only the selected ECG wave’s size
is adjusted. In other screens, all ECG waves’ size is adjusted simultaneously.
You can change the wave sweep speed by selecting [Sweep] and then selecting the
appropriate setting.
