Mindray uMEC12 Operator's Manual

18-1
18 Review
18.1 Accessing Respective Review Windows
1. Select the [Review] QuickKey, or [Main Menu][Review >>].
2. Select [Graphic Trends], [Tabular Trends], [Events], or [Full Disclosure] to access
their respective review windows.
18.2 Reviewing Graphic Trends
In the [Review] menu, select [Graphic Trends] to access the following window.
(1) Event mark area (2) Time axis
(3) Graphic trends area (4) Parameter area
(5) Cursor
Events are marked with colors in the event mark area. Red represents high level alarm event.
Yellow represents medium/low level alarm event. Green represents manual event.
(1)
(2)
(3)
(4)
(5)

Mindray uMEC12 Specifications

General

Type	Patient Monitor
Display	12.1-inch color TFT
ECG	3-lead
SpO2	Yes
NIBP	Yes
Respiration	Yes
Temperature	Yes
Battery	Rechargeable lithium-ion
Networking	Ethernet
Parameters	ECG, SpO2, NIBP, Respiration, Temperature
Connectivity	Ethernet
Battery Life	Up to 4 hours
Power Supply	100-240 VAC, 50/60 Hz
