17-2
17.3 Unfreezing Waveforms
To unfreeze the frozen waveforms, you can either:
Select the
button at the upper right corner of the [Freeze] menu,
Select the
hardkey on the monitor’s front, or
Perform any other action that causes the screen to be readjusted or opens a menu, such
as plugging in or out a module, pressing the
hardkey, etc.
17.4 Recording Frozen Waveforms
1. In the [Freeze] menu, select, in turn, [Wave 1], [Wave 2] and [Wave 3] and then select
your desired waveforms.
2. Select the [Record] button. The selected waveforms and all numerics at the frozen time
are printed out by the recorder.
