Mindray uMEC12 Operator's Manual

16-4
3. Connect the other end of the sampling line to the patient.
 For intubated patients requiring an airway adapter, install the airway adapter
between the patient circuit and the ventilator Y-piece.
 For non-intubated patients, place the nasal cannula onto the patient.
4. Connect the gas outlet to the scavenging system using an exhaust tube.
After the CO
2
module is connected to the SMR, it enters measure mode by default and the
monitor displays CO2 Starting. CO
2
can be measured after the start-up is complete.
WARNING
z Connect the gas outlet to the scavenging system when measuring CO
2
.
Connect to the patient
Connect to the ventilator
Sampling line
Airway adapter

Mindray uMEC12 Specifications

General

Type	Patient Monitor
Display	12.1-inch color TFT
ECG	3-lead
SpO2	Yes
NIBP	Yes
Respiration	Yes
Temperature	Yes
Battery	Rechargeable lithium-ion
Networking	Ethernet
Parameters	ECG, SpO2, NIBP, Respiration, Temperature
Connectivity	Ethernet
Battery Life	Up to 4 hours
Power Supply	100-240 VAC, 50/60 Hz
