Mindray uMEC12 Operator's Manual

26-2
12-Pin Integrative Trunk Cables
Leadwire
supported
Compatible
with
Type Patient
Category
Model Part No.
5-leadwire AHA
Snap,
Defibrillation-proof
Adult,
pediatric
EA6251B 040-000961-00
5-leadwire IEC EA6252B 040-000963-00
3-leadwire AHA EA6231B 040-000965-00
3-leadwire IEC EA6232B 040-000967-00
5-leadwire AHA
Clip,
Defibrillation-proof
EA6251A 040-000960-00
5-leadwire IEC EA6252A 040-000962-00
3-leadwire AHA EA6231A 040-000964-00
3-leadwire IEC EA6232A 040-000966-00
12-Pin Separable Trunk Cables
Leadwire
supported
Compatible
with
Type Patient Category Part No.
3-leadwire AHA, IEC Defibrillation-proof
Infant, neonate
0010-30-42720
3-leadwire AHA, IEC ESU-proof 0010-30-42724
3/5-leadwire AHA, IEC Defibrillation-proof
Adult, pediatric
009-004728-00
3/5-leadwire AHA, IEC ESU-proof 0010-30-42723
12-leadwire AHA Defibrillation-proof
Adult
0010-30-42721
12-leadwire IEC Defibrillation-proof 0010-30-42722
Cable Sets
3-Electrode Cable Sets
Type
Compatible
with
Model
Patient
Category
Part No. Length Remark
Clip
IEC
EL6304A
Adult,
pediatric
0010-30-42732 1m Long
EL6306A
Infant, neonate
0010-30-42897 1m Long
EL6312A 040-000149-00 1m Long
AHA
EL6303A
Adult,
pediatric
0010-30-42731 1m Long
EL6305A
Infant, neonate
0010-30-42896 1m Long
EL6311A 040-000148-00 1m Long

Mindray uMEC12 Specifications

General

Type	Patient Monitor
Display	12.1-inch color TFT
ECG	3-lead
SpO2	Yes
NIBP	Yes
Respiration	Yes
Temperature	Yes
Battery	Rechargeable lithium-ion
Networking	Ethernet
Parameters	ECG, SpO2, NIBP, Respiration, Temperature
Connectivity	Ethernet
Battery Life	Up to 4 hours
Power Supply	100-240 VAC, 50/60 Hz
